Zīmols DAHUA TECHNOLOGY CO., LTD
Artikuls HAC-T1A21P
Svītrkodu: 6939554970528
Piegādātāja noliktavā (49)
Piegades veidi :
Saņemt birojā :
Bezmaksas
1 Darba diena
Omniva :
3.50 €
5 Darba diena
DPD :
5.00 €
5 Darba diena
Unisend Latvia :
2.50 €
5 Darba diena
Piegāde ar kurjeru :
9.00 €
5 Darba diena
Features:
• Max. 30fps@1080P
• HD and SD output switchable
• 2.8mm fixed lens
• Max. IR length 20m, Smart IR
• DC12V
Technical Specifications:
Camera
• Image Sensor 1/2.7" CMOS
• Effective Pixels 1920(H)×1080(V), 2MP
• Scanning System Progressive
• Electronic Shutter Speed PAL: 1/25~1/100000s NTSC: 1/30~1/100000s
• Minimum Illumination 0.04Lux/F1.85, 30IRE, 0Lux IR on
• S/N Ratio More than 65dB
• IR Distance Up to 20m (66feet)
• IR On/Off Control Auto / Manual
Lens
• Lens Type Fixed lens / Fixed iris
• Mount Type Board-in
• Focal Length 2.8mm
• Max Aperture F1.85
• Angle of View H: 93°
• Focus Control N/A
• Close Focus Distance 800mm (500mm, 2000mm)
• Pan/Tilt/Rotation Pan: 0° ~ 360° Tilt: 0° ~ 78° Rotation: 0° ~ 360°
Video
• Resolution 1080P (1920×1080)
• Frame Rate 25/30fps@1080P, 25/30/50/60fps@720P
• Video Output 1-channel BNC high definition video output / CVBS video output (Can switch)
• Day/Night Auto (ICR) / Manual
• OSD Menu Multi-language
• BLC Mode BLC / HLC / DWDR
• WDR DWDR
• Gain Control AGC
• Noise Reduction 2D
• White Balance Auto / Manual
• Smart IR Auto / Manual
Certifications
• CE (EN55032, EN55024, EN50130-4)
• FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
Interface
• Audio Interface N/A
Eelectrical
• Power Supply 12V DC ±30%
• Power Consumption Max. 2.3W (12V DC, IR on)
Environmental
• Operating Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH
• Start up should be done at above -40°C (-40°F)
• Storage Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH
Ingress Protection & Vandal
• Resistance NA
Construction
• Casing Plastic
• Dimensions 85mm×85mm×69mm(3.35"×3.35"×2.72")
• Net Weight 0.09kg (0.20lb)
• Gross Weight 0.13kg (0.27lb)
